LM386 LTSpice Model

Thread Starter

aac044210

Joined Nov 19, 2019
151
Hi:

I have downloaded an LTSpice model for the LM386. Can some explain to me how
I would get this model working. Note I only have a .sub file. I have attached the file.
Thanks very much.


Papabravo

Joined Feb 24, 2006
14,448
You need to have a symbol, in an ".asy" files that points to the ".sub" file.
Which version of LTspice are you working with?
Have you seen the YouTube video on this subject?


Alec_t

Joined Sep 17, 2013
11,650
One option is to copy the model text and paste it as a directive onto a blank LTS schematic. Then click 'Hierarchy/Open this sheet's symbol' and answer 'yes' to the pop-up request to generate a symbol automatically. Once you have that symbol you can edit it as you wish within the LTS editor.


Thread Starter

aac044210

Joined Nov 19, 2019
151
It edits fine in my LTS (version XV11). In File Explorer, just double-click on the file name and LTS should pop up as the default app to open it.
Thanks Alec.

When I try to run a sim with the LM386, it says "Could not open library file LM386.sub". I see that the file extension is txt rather than sub. Now
the error msg makes sense. Not sure what to do.

Last edited:

Bordodynov

Joined May 20, 2015
2,661
My collection of models has this chip. The model (actually two models Lm386 and Lm386_) is in the Lm386.sub file in the SUB folder. In the folder ...Documents\LTspiceXVII\lib\sym\ZZZ\Sound_Amplifiers is the file of the symbol LM386.asy. With this symbol, any model from Lm386 and Lm386_ is called.
Here is the link:
http://bordodynov.ltwiki.org/


Thread Starter

aac044210

Joined Nov 19, 2019
151
My collection of models has this chip. The model (actually two models Lm386 and Lm386_) is in the Lm386.sub file in the SUB folder. In the folder ...Documents\LTspiceXVII\lib\sym\ZZZ\Sound_Amplifiers is the file of the symbol LM386.asy. With this symbol, any model from Lm386 and Lm386_ is called.
Here is the link:
http://bordodynov.ltwiki.org/
Thanks Bordodynov. Do you have a model for the
My collection of models has this chip. The model (actually two models Lm386 and Lm386_) is in the Lm386.sub file in the SUB folder. In the folder ...Documents\LTspiceXVII\lib\sym\ZZZ\Sound_Amplifiers is the file of the symbol LM386.asy. With this symbol, any model from Lm386 and Lm386_ is called.
Here is the link:
http://bordodynov.ltwiki.org/
Thanks Bordodtnov. Do you have a model for the 4026 Decade Counter / Divider?


atferrari

Joined Jan 6, 2004
4,095
Thanks Bordodynov. Do you have a model for the

Thanks Bordodtnov. Do you have a model for the 4026 Decade Counter / Divider?
My suggestion: download the whole lot from his site. No toasters or TVs yet but probably most of what you will need in the next two years. Make sure you explore the full thing; it's a rich trove of models of all kinds.
