When you are wiring multiple buses such as encountered in microcontroller experimentation, breadboarding becomes painful.

There are three options (almost all obsolete) that I have used successfully in the past.

1) wire-wrapping, if you can locate wire-wrap DIP sockets

2) Scotch-3M IDC breadboarding system (I have to look up the correct terminology) - which is probably impossible to source. This, by far, is the most efficient breadboarding technique. You simple run wire-wrap wire to each connection point and press it in. It allows you to lay continuous runs of a signal wire.

3) Using special wire insulated with a thermo-plastic coating. You simply wire from point-to-point using your soldering iron. The heat from the soldering iron melts the plastic coating and solders the end of the wire to the solder pad. As above, you can lay continuous runs of one signal without having to cut the wire.

I can't find wire wrap sockets

is this any good? Using wires



please you read books before building such yh?
Please what books if you remember? I want to do these things.
I know you mentioned tv typewriter before

Thanks

My Z-80 books from that era.

https://archive.org/details/The_Z-80_Microcomputer_Handbook
https://archive.org/details/bitsavers_zilogdataBomputerComponentsDataBook_35001301



I can't find wire wrap sockets

is this any good? Using wires

That protoboard is OK.
I prefer to use protoboards that are specifically designed for DIP packages. It will have at least two power rails running down in between 0.3" spaced pads.

For wiring, look up Belden Beldsol solderable magnet wire.



That protoboard is OK.
I prefer to use protoboards that are specifically designed for DIP packages. It will have at least two power rails running down in between 0.3" spaced pads.

For wiring, look up Belden Beldsol solderable magnet wire.

Thanks...never seen a protoboard(not solderless breadboard) with power rails. Good, thanks



Hello,

For protoboard with power lines have a look here:
https://www.electrodragon.com/product/2pcs-soldering-prototype-board-breadboard-style/

Bertus



For old school wire.
https://www.vectorelect.com/slit-n-wrap-wire.html

I don't typically wrap prototype boards now but I still use vector products because they have well designed power and ground rails.
https://www.vectorelect.com/3677-2.html



For old school wire.
https://www.vectorelect.com/slit-n-wrap-wire.html

I don't typically wrap prototype boards now but I still use vector products because they have well designed power and ground rails.
https://www.vectorelect.com/3677-2.html

Surely going to get your books to study them

Thanks again



What about the tools? I used to have a couple of those things laying about. No idea where they walked off too in the past 30 years.

Not too bad from China. This is the one I remember.

https://www.ebay.com/itm/WSU-Wire-W...pid=6023917884&hash=item5d814cc510:rk:15:pf:0

A always like the strippers on those things.



What about the tools? I used to have a couple of those things laying about. No idea where they walked off too in the past 30 years.

Not too bad from China. This is the one I remember.

https://www.ebay.com/itm/WSU-Wire-W...pid=6023917884&hash=item5d814cc510:rk:15:pf:0

A always like the strippers on those things.

Not sure I would use wire wrap method..Difficult finding the dip sockets for it



Not sure I would use wire wrap method..Difficult finding the dip sockets for it

The wire-wrap gun might still be available from Gardner-Denver



Not sure I would use wire wrap method..Difficult finding the dip sockets for it

I already posted a link

https://www.ebay.com/sch/i.html?_from=R40&_trksid=m570.l1313&_nkw=wirewap+sockets&_sacat=0

Bet you can find them on aliexpress too.



The wire-wrap gun might still be available from Gardner-Denver

They ain't cheap. $00 or more from what I have seen. I didn't even have one assigned to me at work. I really wasn't doing enough wrapping to justify it.



I already posted a link

https://www.ebay.com/sch/i.html?_from=R40&_trksid=m570.l1313&_nkw=wirewap+sockets&_sacat=0

Bet you can find them on aliexpress too.

hmm, please help me search on aliexpress...I searched but only found the ones with one pin in a row (1 * 24)

Thanks if you can



hmm, please help me search on aliexpress...I searched but only found the ones with one pin in a row (1 * 24)

Thanks if you can

In the TO area check out Sayal and CreatronInc.

https://sayal.com/STORE/ActionIndexP.asp?ID=213860



In the TO area check out Sayal and CreatronInc.

https://sayal.com/STORE/ActionIndexP.asp?ID=213860

Sayal sucks...I got 2 eeproms AT28c256 for I think $25 or $35 each...getting 10 for $15 on aliexpress



What about the tools? I used to have a couple of those things laying about. No idea where they walked off too in the past 30 years.

I'm on my second wire wrap tool. The first one died a hideous death 40-some years ago when my ex-wife (before she became an ex-) mistook it for a nail set and attempted to use it to recess some nails in some woodwork. Mangled the livin' daylights out of it. When I came home from work she held it up for me to look at and said, "See what a piece of crap this nail set is? Don't ever buy another one of those again!"

Sigh...



I'm on my second wire wrap tool. The first one died a hideous death 40-some years ago when my ex-wife (before she became an ex-) mistook it for a nail set and attempted to use it to recess some nails in some woodwork. Mangled the livin' daylights out of it. When I came home from work she held it up for me to look at and said, "See what a piece of crap this nail set is? Don't ever buy another one of those again!"

Sigh...

lol...btw, why ex? because of this??



lol...btw, why ex? because of this??

Long story; we'll just skip it...



post hoc, ergo propter hoc!



I remember a WW tool that could be used for bussing. You didn't have to strip the wire. never used it.

A Auger Mass Spectrometer UHV (Ultra-High Vacuum - ION pumped) SEM (Scanning Electron Microscope) made by Kevex gave me the fits though. The production board was wire wrapped. A number that the operator needed was in a specific color and that color or the actual number would disappear sometimes. Long before real computers and displays. PDP-11 based, Color display. That system was a mass of cables.

The operator had to move it and labeled all of the cables. I didn't understand his labeling method, but it involved dice type dot markings with multiple color dots (Stadtler permanent marker Pens). Low tech. No fancy labelmakers back then.

Aside: We bought a 3-source e-beam evaporator via auction and "THEY" cut all of the wires from the e-beam controller to the vacuum system.

There were connectors, they were just hidden in the rack. They were betting it would never run, I had no help putting it all back together. I wish they would have not cut the three high voltage cables (there were lugs).

It was "sort of" a lemon, because the e-beam sources were designed badly which the manufacturer admitted. I think it was about 9K if we wanted new sources. Power source 90 A 208 3 phase 5 wire. The equipment cabinet switched the neutral which is permitted.

For the Kevex unit, the manufacturer bussed the power and ground pins by soldering only those pins to a PCB. Everything else was wire-wrapped. They missed one or two solder joints on an IC. Took like 7 years for the problem to show up and I had to find it.
