Hi! Would you mind sharing your LTSpice model of the CD4024?? I can't find one anywhere!



Post moved from here.



hi dev,
Unzip this CDseries.zip.
I would recommend you join the free LTS User Yahoo group, lots of good informatio and help.
E



Hi, I saw this thread when searching for the CD4024 counter. Great library!
I'm quite new to LTspice (Still a student).
I'm having trouble using the components as my LTSpice can't find the CDlogic.sub file (I added .include CDlogic.sub).
Any ideas where I can find this file or how I can get the simulation running without it?
Thanks



hi Ode,
Welcome to AAC,
Unzip the zip file in post #5
You should see CDlogic & CD4000.lib

Place the CDlogic in the 'sym' folder
& the
CD4000.lib in the'lib' folder.

When you create a asy file, type in the circuit .inc cd4000.lib
Use F2 to show the CD4000 contents
OK.?
E


EDIT:
Added sample asc file



Thanks for the quick reply!
I forgot to mention, I'm using a mac with macOS (don't know if that matters).
I'm not sure I understand. When I open a new schematic it generates a .asc file, right? I added the .include cd4000.lib and I get the following error:
I downloaded your example file and when I ran it gave me the following error.

I feel like there's something I'm missing, when I go to the component menu, I can see all of the CDlogic components.
Is it possible I have some LTspice files missing?



hi,
I dont' use MAC, post your asc file, I will run it.
E

Update:
Have you got the 74HCT lib installed.?
If not delete those two 151 symbols and try the 4024 on its own.



I tried running your asc file without the 73HCT components (even though I have it installed), gave me the same error as in the asc file I created..
This is my asc file.
Thanks!



hi,
Your Exp asc file runs OK in Win10. I know we have had problems with MAC and LTS.
I will Tag other LTS users, they may have a fix.

E

@eetech00
@Bordodynov
@Alec_t



Ok thanks a lot for your help! Hope to figure it out soon

Oded



hi,
This is the 74HCT for LTS.
E



hi,
Your Exp asc file runs OK in Win10. I know we have had problems with MAC and LTS.
I will Tag other LTS users, they may have a fix.

E

@eetech00
@Bordodynov
@Alec_t

If you have installed the 74HCT.lib file, the error indicates that LTspice cannot find the 74HCT.lib file.
To troubleshoot, try placing the 74HCT.lib file in the same folder as the schematic file (.asc file). That should work because LTspice will automatically look in the schematic folder.



Hi @eetech00 ,
I moved the .lib file to the same folder as my .asc file but still no luck.
I'm not sure if the problem is with the .lib file after all. I keep getting the following error message:
'u1:in1:b1: Unknown circuit node: "vdd" requested in behavioral source.'
Does this maybe have something to do with the attributes in the netlist line or something?

EDIT: Ok, I renamed one of the nets "VDD" and all of a sudden the simulation started working. The counter won't count, but at least it's running

Thanks,
Oded



Hi @eetech00 ,
I moved the .lib file to the same folder as my .asc file but still no luck.
I'm not sure if the problem is with the .lib file after all. I keep getting the following error message:
'u1:in1:b1: Unknown circuit node: "vdd" requested in behavioral source.'
Does this maybe have something to do with the attributes in the netlist line or something?

EDIT: Ok, I renamed one of the nets "VDD" and all of a sudden the simulation started working. The counter won't count, but at least it's running

Thanks,
Oded

Yes. When using the 74HCT.lib or CD4000.lib library parts, they expect a power supply net labeled "VDD".



Does the Sim program know that the counter is a ripple type and not a synchronous type?



Does the Sim program know that the counter is a ripple type and not a synchronous type?

The sim program understands the math behind both type of devices.



Hi @eetech00 ,
I moved the .lib file to the same folder as my .asc file but still no luck.
I'm not sure if the problem is with the .lib file after all. I keep getting the following error message:
'u1:in1:b1: Unknown circuit node: "vdd" requested in behavioral source.'
Does this maybe have something to do with the attributes in the netlist line or something?

EDIT: Ok, I renamed one of the nets "VDD" and all of a sudden the simulation started working. The counter won't count, but at least it's running

Thanks,
Oded

Hi I am facing with the same problem. Could you please tell me which net did you renamed?

Thanks in advance.



Although the model doesn't have explicit power pins it needs a power supply voltage source in the schematic. The positive rail of that source needs a label vdd.



from LTspice sampling : A_devices have 8 connections. 5 (1-5) inputs, complement out on (6), out on (7) & common on (8), then function specifier, then optional specifications.
;.syntax:.A#...IN1..IN2..IN3..IN4..IN5..-OUT.+OUT.GND..DEVICE...extra specification... UNUSED PINS SHOULD SHUNT TO 8=GND=net0
