Hi friends,
I am an absolute beginner and getting my feet wet in Digital Electronics. Could someone please help me in identifying the pins on the pbs-110-c switch. There are 6 of them and I don't know what they do.

I have attached an image of what it looks like.

Thanks,
Tony


Attachments

EM Fields

EM Fields

Joined Jun 8, 2016
583
Tony201700 said:
Hi friends,
I am an absolute beginner and getting my feet wet in Digital Electronics. Could someone please help me in identifying the pins on the pbs-110-c switch. There are 6 of them and I don't know what they do.

I have attached an image of what it looks like.

Thanks,
Tony
Click to expand...
Do you have an ohmmeter or a continuity tester?
