Simple control circuit needed

Discussion in 'The Projects Forum' started by SevenLeft, Apr 14, 2018.

  1. SevenLeft

    Thread Starter New Member

    Apr 14, 2018
    2
    0
    Hello all,
    I am in need of a simple control circuit that I am realizing to be more of a challenge for me than I thought! The supply voltage will be about 5V and one push button will be used to control the device. There is also 2 LEDs. LED1 used when supply voltage >2V. LED2 when supply voltage is 2V or less. When the device is off, the button can be pressed and nothing will happen. The button must be pressed 3 times within 1 second for the device to turn on. After pressing the button 3 times, the LED will flash 3 times to signify the device is on. Once on, as soon as the button is pressed, the LED will turn on and the load will be powered (small low temp heater). When button is let go, the LED and load will both turn off. This will continue until the button is pressed 3 times within 1 second turning the device off and also having the LED flash 3 times.
    All other components needed are constricted to a diameter of about 1 cm! So any help on how to accomplish this task in the most space saving and cheapest way possible will be greatly appreciated!
    Thanks!

  2. danadak

    Well-Known Member

    Mar 10, 2018
    1,746
    357
  3. crutschow

    Expert

    Mar 14, 2008
    20,067
    5,651
    Yup, sounds like you need a microcontroller such as danadak suggested.

    -live wire- likes this.
  4. danadak

    Well-Known Member

    Mar 10, 2018
    1,746
    357
    Last edited: Apr 15, 2018
  5. SevenLeft

    Thread Starter New Member

    Apr 14, 2018
    2
    0
    Are you able to use the state machine wizard in PSOC with microcontrollers such as ATTINY85 and PIC10F200?

  6. danadak

    Well-Known Member

    Mar 10, 2018
    1,746
    357
