PNP equivalent for 2n2222?

Discussion in 'General Electronics Chat' started by Razor Concepts, Apr 22, 2009.

  1. Razor Concepts

    Thread Starter Senior Member

    Oct 7, 2008
    212
    1
    What is the PNP equivalent of the NPN 2222 transistor? I just want a general purpose PNP transistor.

  2. hgmjr

    Moderator

    Jan 28, 2005
    9,030
    218
    I am accustomed to using the 2N2907 or 2N2907A as the complement to the 2N2222 or 2N2222A.

    hgmjr

    Tonyr1084 likes this.
  3. Ron H

    AAC Fanatic!

    Apr 14, 2005
    7,049
    672
    That would be my choice also. The plastic package is PN2907.

  4. Wendy

    Moderator

    Mar 24, 2008
    21,175
    2,870
    Ditto, the PN2222 is also the plastic version.

  5. xainnasir

    Member

    Nov 8, 2012
    29
    3
    Hi,

    If you are working on 2n2222, then you should have a look at Introduction to 2n2222. They have explained it in detail and have also shared its Proteus Simulation.

    Thanks.

  6. be80be

    AAC Fanatic!

    Jul 5, 2008
    1,445
    269
    I like the 2n3904 and the 2n3906 but the 2N2907 works with the 2n2222
    but for most stuff the 2n3904 and 2n3906 match better

  7. xainnasir

    Member

    Nov 8, 2012
    29
    3
    It depends on the application as well, they have some differences in their operations so I would suggest you to read their datasheets first.

  8. Hymie

    Member

    Mar 30, 2018
    71
    17
    People seem to get hung-up on replacing transistor with what they have been informed is a compatible replacement.

    Back in the day when hi-fi amplifiers used discrete components in their construction – I was often called upon to repair friends/acquaintances amplifiers that had ceased working.
    All I had in my selection of available transistors was six variants (low, medium and high power – one of each flavour, PNP & NPN).

    Consulting my copy of Towers Transistor Selector to ensure that the voltage (C-E) was adequate and the pin out arrangement was all I needed.

    Even today, I have plastic box with separate compartments to store transistors, each compartment is labelled with the transistor number, NPN/PNP, pin out, max C-E voltage, max collector current and power dissipation. So unless there is some special requirement, such as high gain or high frequency, for 99% of the circuits I build or repair this is all I need to know.

  9. Reloadron

    Distinguished Member

    Jan 15, 2015
    2,988
    1,323
    This thread began in April 2009. I sincerely hope the original poster, who had a single post, has found a compliment to the 2N2222 by now. :) While I agree the 2N2907 is a close complimentary fit one should review the data sheets to make sure, in their application, the selected compliment will work, as others have mentioned. Now if we wait till April of 2019 we will have a 10 year old thread.

    Ron

  10. crutschow

    Expert

    Mar 14, 2008
    18,258
    5,064
    Our new necroposter, xainnasir, has been a busy lad lately. :rolleyes:

    Reloadron likes this.
  11. Reloadron

    Distinguished Member

    Jan 15, 2015
    2,988
    1,323
    It would seem so. :)

    Ron

  12. ebp

    Active Member

    Feb 8, 2018
    746
    218
    My guess is using signature line to pimp website.
