Super Position with dependent circuit

Discussion in 'Homework Help' started by gengm, Apr 12, 2010.

  1. gengm

    Thread Starter New Member

    Apr 7, 2010
    23
    0
    Here is the problem
    [​IMG]
    I'm having problems taking the Vb and the relation of the Dependent CS both when I try to short the VS and open the CS
    Would Mesh Analysis work in the case of the VS, and then Node Analysis in the case of the CS?

    Last edited: Apr 12, 2010
  2. hgmjr

    Moderator

    Jan 28, 2005
    9,030
    214
    Have you considered simplifying the circuit by replacing the 10A current source and the 20 ohm resistor with its Norton Equivalent?

    hgmjr

  3. gengm

    Thread Starter New Member

    Apr 7, 2010
    23
    0
    Oh! I never considered that
    Also I updated the picture.

    Last edited: Apr 12, 2010
  4. The Electrician

    AAC Fanatic!

    Oct 9, 2007
    2,281
    326
    A current source in parallel with a resistor is a Norton equivalent, isn't it?

    Perhaps you meant Thevenin equivalent.

  5. hgmjr

    Moderator

    Jan 28, 2005
    9,030
    214
    Electrician, You are absolutely correct. Thanks for that clarification. You will have to forgive my momentary lapse.

    Apologies to gengm for the mistake. I should have said convert the 20 ohm resistor and the paralleled 10A current source into their Thevenin's equivalent as the Electrician has indicated.

    hgmjr
