Can someone check my solution?

Discussion in 'Homework Help' started by Loki4000, Dec 11, 2011.

  1. Loki4000

    Thread Starter Member

    Sep 29, 2011
    22
    0
    Can someone check my solution?

    If my solution is wrong can someone explain my errors?

    [​IMG]
    my solution:
    [​IMG]

  2. who_me_yes_you

    New Member

    Dec 7, 2011
    8
    0
    Its been a while since I have calculated equivalent circuits; however I am getting different answers than you. How are you calculating the equivilant impedance? How are you calculating the Thevenin Voltage and Norton Current? One thing I would comment on is your notation. Use a universal notation that you should have been taught eg, Vth is Thevenin voltage, Rth Thevenin impedance etc

  3. thatoneguy

    AAC Fanatic!

    Feb 19, 2009
    6,357
    718
    OP Answer is incorrect.

    Try re-drawing the schematic so all of the resistors are vertical, but the connections are the same.

    Then the method of calculating it should jump out at you.
